Siemens Micromaster 440 frequency converter 6SE6440-2UD41-3GA1 converter 160kW

Siemens Micromaster 440 Frequency Converter 132/160 kW

The Micromaster 440 frequency converter is suitable for a wide range of variable speed applications.

Its flexibility enables its use in a wide variety of areas, including cranes and hoists, high-bay warehouses, machinery for the food, beverage and tobacco industries, packaging machines and much more. These applications require an above-average level of functionality and dynamics from the frequency converter.

The inverter is particularly characterized by its customer-oriented performance and user-friendliness. Its wide mains voltage range enables worldwide use.

- Easy, guided commissioning
- Modular design for maximum configuration flexibility
- Low-noise motor operation thanks to high, adjustable pulse frequencies (observe possible power derating)
- Protection for motor and inverter
- EMC filter, optional Class A/B
- State-of-the-art IGBT technology
- High-quality PID controller for easy internal process control (automatic optimization)
- Special direct connection for PTC or KTY for motor protection
- Blocking protection for the motor

Technical data

Manufacturer: Siemens
Series: Micromaster 440
Model: 6SE6440-2UD41-3GA1

Input voltage:
380–480 V ±10 %
3 A AC
297 A
47–63 Hz

Output:
0 - Input V
3 AC
250 A
0 - 650 Hz
Constant torque 132 kW
Square torque 160 kW

Dimensions:
1533 x 326 x 545 mm (H x W x D)
Weight: 170 kg
