Logopak 920 II PF Pallet Labeler

Manufacturer: Logopak
Pallet Labeler
Model: 920 II PF

Your benefits at a glance

Top speed (up to 240 pallets/hour)
Fewer roll changes
Maximum flexibility
Robust construction (protective housing)
Intuitive operation via touchscreen
Print Engine Quick Change System
Thermal direct or thermal transfer printing for labels up to A3
Internal database, error diagnosis and many other features
Functions as a stand-alone solution or integrated into the network

VLP 210 II F Label Printing System

The Logopak VLP 210 is an intelligent label printing system for barcode product identification.
The robust mechanical design of the 10 mm thick die-cast aluminum housing with solid steel hinge plates was specially developed for continuous operation in harsh industrial environments.

The printer can be controlled externally via a serial interface or operated as a standalone device thanks to its integrated intelligence.

SPECIFICATIONS
Printing speed: 150 mm/s
Core diameter: 50 mm/76 mm
Label roll diameter: 180 mm
Font size: 2 mm–50 mm
Print direction: Rotatable by 90°, 180° and 270°
Barcode types: Codabar, Code39, Code128, CodeMatrix
EAN13, EAN8, EAN-128, Lata 2/5, Industrial 2/5, Interleave 2/5, ITF-14, Maxicode, PDF417, QR, UPC-A
Interface: V.24 or 20 mA, network-capable
Memory (RAM): 1 MB battery-buffered CMOS memory, expandable to 8 MB
Ambient temperature: 5 °C to 40 °C
Dimensions (W x L x H): 700 mm x 500 mm x 400 mm
Weight: approx. 50 kg
Housing: Painted steel

Integrated Intelligence: IP54 control unit with Power Leap II® processing power
• User-friendly control panel with color LCD display and touchscreen
• Multilingual control panel (standard)
• Internal article database and error logging (standard)
• Remote maintenance for software updates (optional)
• 10 standard fonts, 4 scalable
• Dual 64-bit RISC processors, 150 MHz clock
• RS 422 and 20 mA, Ethernet connection also available (10/100 Mbit)
• Industrial fieldbus for I/O control (CAN bus) with flexible programming using higher PLC language
• Up to 200 digital I/Os for process control without loss of efficiency

Find more items - new and used - in our shop!
International shipping costs on request!

SPECIFICATIONS
Print speed: 150 mm/s
Core diameter: 50 mm/76 mm
Label roll diameter: 180 mm
Font size: 2 mm–50 mm
Print direction: Rotatable by 90°, 180° and 270°
Barcode types: Codabar, Code39, Code128, CodeMatrix
EAN13, EAN8, EAN-128, Lata 2/5, Industrial 2/5, Interleave 2/5, ITF-14, Maxicode, PDF417, QR, UPC-A
Interface: V.24 or 20 mA, network-capable
Memory (RAM): 1 MB battery-buffered CMOS memory, expandable to 8 MB
Ambient temperature: 5 °C to 40 °C
Dimensions (W x L x H): 700 mm x 500 mm x 400 mm
Weight: approx. 50 kg
Housing: Painted steel

Integrated intelligence: IP54 control unit with Power Leap II®-processing power
• User-friendly control panel with color LCD display and touchscreen
• Multilingual control panel (standard)
• Internal article database and error logging (standard)
• Remote maintenance for software updates (optional)
• 10 standard fonts, 4 scalable
• Dual 64-bit RISC processors, 150 MHz clock
• RS 422 and 20 mA, Ethernet connection also available (10/100 Mbit)
• Industrial fieldbus for I/O control (CAN bus) with flexible programming using higher PLC language
• Up to 200 digital I/Os for process control without loss of efficiency
